Артикул |
D1 |
D2 |
D3 |
L |
ET |
Ход |
Обозначение |
|
50722823 |
22 - 26 mm |
18 mm |
28 mm |
25 / 40 mm |
230 mm |
50 mm |
Füller 5072.28 ET-230/28/Hub-50/18
|
|
50722833 |
22 - 26 mm |
18 mm |
28 mm |
25 / 40 mm |
330 mm |
50 mm |
Füller 5072.28 ET-330/28/Hub-50/18
|
|
50722843 |
22 - 26 mm |
18 mm |
28 mm |
25 / 40 mm |
430 mm |
50 mm |
Füller 5072.28 ET-430/28/Hub-50/18
|
|
50722853 |
22 - 26 mm |
18 mm |
28 mm |
25 / 40 mm |
530 mm |
50 mm |
Füller 5072.28 ET-530/28/Hub-50/18
|
|
50722863 |
22 - 26 mm |
18 mm |
28 mm |
25 / 40 mm |
630 mm |
50 mm |
Füller 5072.28 ET-630/28/Hub-50/18
|
|
50723223 |
22 - 26 mm |
18 mm |
32 mm |
25 / 40 mm |
230 mm |
50 mm |
Füller 5072.32 ET-230/32/Hub-50/18
|
|
50723233 |
22 - 26 mm |
18 mm |
32 mm |
25 / 40 mm |
330 mm |
50 mm |
Füller 5072.32 ET-330/32/Hub-50/18
|
|
50723243 |
22 - 26 mm |
18 mm |
32 mm |
25 / 40 mm |
430 mm |
50 mm |
Füller 5072.32 ET-430/32/Hub-50/18
|
|
50723253 |
22 - 26 mm |
18 mm |
32 mm |
25 / 40 mm |
530 mm |
50 mm |
Füller 5072.32 ET-530/32/Hub-50/18
|
|
50723263 |
22 - 26 mm |
18 mm |
32 mm |
25 / 40 mm |
630 mm |
50 mm |
Füller 5072.32 ET-630/32/Hub-50/18
|
|
50724023 |
22 - 36 mm |
18 mm |
40 mm |
25 / 40 mm |
230 mm |
50 mm |
Füller 5072.40 ET-230/40/Hub-50/18
|
|
50724033 |
22 - 36 mm |
18 mm |
40 mm |
25 / 40 mm |
330 mm |
50 mm |
Füller 5072.40 ET-330/40/Hub-50/18
|
|
50724043 |
22 - 36 mm |
18 mm |
40 mm |
25 / 40 mm |
430 mm |
50 mm |
Füller 5072.40 ET-430/40/Hub-50/18
|
|
50724053 |
22 - 36 mm |
18 mm |
40 mm |
25 / 40 mm |
530 mm |
50 mm |
Füller 5072.40 ET-530/40/Hub-50/18
|
|
50724063 |
22 - 36 mm |
18 mm |
40 mm |
25 / 40 mm |
630 mm |
50 mm |
Füller 5072.40 ET-630/40/Hub-50/18
|
|
50724223 |
22 - 36 mm |
18 mm |
42 mm |
25 / 40 mm |
230 mm |
50 mm |
Füller 5072.42 ET-230/42/Hub-50/18
|
|
50724233 |
22 - 36 mm |
18 mm |
42 mm |
25 / 40 mm |
330 mm |
50 mm |
Füller 5072.42 ET-330/42/Hub-50/18
|
|
50724243 |
22 - 36 mm |
18 mm |
42 mm |
25 / 40 mm |
430 mm |
50 mm |
Füller 5072.42 ET-430/42/Hub-50/18
|
|
50724253 |
22 - 36 mm |
18 mm |
42 mm |
25 / 40 mm |
530 mm |
50 mm |
Füller 5072.42 ET-530/42/Hub-50/18
|
|
50724263 |
22 - 36 mm |
18 mm |
42 mm |
25 / 40 mm |
630 mm |
50 mm |
Füller 5072.42 ET-630/42/Hub-50/18
|
|
50724323 |
22 - 36 mm |
18 mm |
M42x1,5 |
25 / 40 mm |
230 mm |
50 mm |
Füller 5072.43 ET-230/M42/Hub-50/18
|
|
50724333 |
22 - 36 mm |
18 mm |
M42x1,5 |
25 / 40 mm |
330 mm |
50 mm |
Füller 5072.43 ET-330/M42/Hub-50/18
|
|
50724343 |
22 - 36 mm |
18 mm |
M42x1,5 |
25 / 40 mm |
430 mm |
50 mm |
Füller 5072.43 ET-430/M42/Hub-50/18
|
|
50724353 |
22 - 36 mm |
18 mm |
M42x1,5 |
25 / 40 mm |
530 mm |
50 mm |
Füller 5072.43 ET-530/M42/Hub-50/18
|
|
50724363 |
22 - 36 mm |
18 mm |
M42x1,5 |
25 / 40 mm |
630 mm |
50 mm |
Füller 5072.43 ET-630/M42/Hub-50/18
|
|
50725023 |
22 - 36 mm |
18 mm |
50 mm |
25 / 40 mm |
230 mm |
50 mm |
Füller 5072.50 ET-230/50/Hub-50/18
|
|
50725033 |
22 - 36 mm |
18 mm |
50 mm |
25 / 40 mm |
330 mm |
50 mm |
Füller 5072.50 ET-330/50/Hub-50/18
|
|
50725043 |
22 - 36 mm |
18 mm |
50 mm |
25 / 40 mm |
430 mm |
50 mm |
Füller 5072.50 ET-430/50/Hub-50/18
|
|
50725053 |
22 - 36 mm |
18 mm |
50 mm |
25 / 40 mm |
530 mm |
50 mm |
Füller 5072.50 ET-530/50/Hub-50/18
|
|
50725063 |
22 - 36 mm |
18 mm |
50 mm |
25 / 40 mm |
630 mm |
50 mm |
Füller 5072.50 ET-630/50/Hub-50/18
|
